Performance and versatility in a single machine for any welding project!
Take your projects to the next level with the EvoTools +Plus® WMI 135 welding inverter, a state-of-the-art, fully digitalized piece of equipment. This versatile device offers three essential welding processes: MMA, MIG/MAG (with gas or gasless/FCAW) and TIG Lift, making it the ideal solution both for maintenance workshops and for DIY enthusiasts who need precision and power in a compact format.
Equipped with an LED display for parameter monitoring and software control, the WMI 135 ensures a constant output current for clean, durable welds. The inverter includes advanced functions such as Anti-stick, Arc Force and Hot Start, which make arc ignition easier and prevent electrode sticking. The robust construction, forced ventilation and built-in protection against overload and overheating ensure a long service life for the machine.
Technical specifications:
Supply voltage: 220-240V / 50-60Hz
Rated welding current: 135A
Current adjustment range: 20A - 135A
Electrode diameter (MMA): 1.6 mm - 3.2 mm
Welding wire diameter (MIG): 0.8 mm - 1.0 mm
Wire feed speed: 1.5 - 15 m/min
Duty cycle (MMA, MIG/MAG, TIG Lift): 60% at 135A,
Maximum absorbed power (MIG/MAG): 4.6 Kw
Maximum absorbed power (MMA): 5.9 Kw
Maximum absorbed power (TIG): 3.4 Kw
Protection: Overheating and overload (IP21S)
Accessories:
- MIG/MAG torch, EURO Torch type
- TIG Lift torch
- Electrode holder with cable
- 300A earth clamp with cable
- Wire drive rollers (for ∅0.8 mm and ∅1.0 mm)
- Welding mask
- Wire brush with chipping hammer
Functions:
MMA welding, MIG/MAG (Gas/No Gas), TIG Lift,
Anti-Stick: Prevents the electrode from sticking during MMA welding.
Hot Start: Ensures easy arc ignition in MMA welding.
Arc Force: Optimizes arc stability depending on the distance from the workpiece in MMA welding.
