Brand:
Description:
This type of pump is used for irrigating small gardens, supplying clean water in temporary installations, transferring non-corrosive liquids, and filling/emptying small tanks and pools. Easy to transport thanks to the handle with which it is equipped and its low weight.
It is equipped with an electric float switch for automatic starting and stopping of the pump when the water level drops below the minimum level.
Thanks to the materials used to manufacture the pump, ABS and stainless steel, the risk of rust formation is considerably reduced.
On the lower part of the pump body there is a ring with which you can adjust the pump according to the type of water, clean or dirty water.
By turning the ring to the 23 mm position, the slots through which the water enters are fully open. This setting is used for dirty water with impurities that do not exceed 5 mm. In this case the pump has the highest (maximum) flow rate.
By turning the ring to the 1 mm position, the slots through which the water enters are almost closed. In this case it is possible to pump water from the lowest level mentioned in the technical documentation.
Specific operating details:
Resistant to solid particles in suspension (sand, sludge).
Technical data:
Rated power: 750 W (682530) / 1000 W (682531)
Maximum immersion depth: 7 m
Maximum pumping height: 8.5 m (682530) / 10.5 m (682531)
Maximum flow rate: 266 L/min (682530) / 308 L/min (682531)
Maximum working pressure: 0.85 bar (682530) / 1.05 bar (682531)
Solid particle size: 5 mm
Maximum temperature of pumped liquid: 35 °C
Shredder: No
Carrying handle: Yes
Protections: thermal, with automatic reset
Connection: 25/32 mm
Electric cable length: 10 m
Protection rating: IPX8
Weight: ~ 7 kg (682530) / 7.5 kg (682531)
WARNING!!!
USE IN SEPTIC TANKS AND/OR TOILET SEWER SYSTEMS IS PROHIBITED!
Characteristics:
Documentation:
